Spool Roll PET Tape
* Insulation / Lithium battery extremely car fixed
* Transform coil wrapping and fixed
* Chip insetting.
* 3D printer
Product Details
Product Description
Spool roll PET tape consists of a polyester film backing, single side coated with silicone adhesive. PET tape is designed to perform difficult masking operations such as the masking of surfaces during the application of durable powder coating.
Feature
* PET film tape is easy to apply and remove and leaves no residue on the surface
* Green pet tape has good viscosity, good serviceability, high temperature, and excellent electrical properties.
* Excellent initial adhesion and adhesion; no glue residue, no edge warping, no shedding after baking; solvent resistance; acid and alkali resistance; long-term temperature resistance of 220 ℃
Construction
Physical Properties
Item | NKS-3565SIG | NKS-5080SIG | NKS-2560SIG | NKS-2590SIG |
Color | Clear/Green/Blue | Clear/Green/Blue | Clear/Green/Blue | Red/Yellow |
Carrier | Polyester | Polyester | Polyester | Polyester |
Adhesive | Silicone | Silicone | Silicone | Silicone |
Carrier Thickness (mm) | 0.035 | 0.05 | 0.025 | 0.025 |
Adhesive Thickness (mm) | 0.025 | 0.03 | 0.035 | 0.065 |
Total Thickness (mm) | 0.06 | 0.08 | 0.060 | 0.09 |
Adhesion (N/25mm) | 6 | 6 | 6 | 8 |
Tensile Strength (N/25mm) | 135 | 220 | 115 | 135 |
Elongation at Break (%) | 40 | 50 | 35 | 35 |
Corrosion Resistance | 1 | 1 | 1 | 1 |
Storage Condition | 20℃,65RH | 20℃,65RH | 20℃,65RH | 20℃,65RH |
Long Term Heat Resistance (℃) | 180 | 180 | 180 | 180 |
Short Term Heat Resistance (℃) | 220 | 220 | 220 | 220 |
RoHS | Complied | |||
Width | 2~980mm | |||
Length | 33m/66m | |||
These values are measured values and not guaranteed values.
Production Process
Application
Spool roll PET tape is used for converting, masking adhesive seams in metal bonding processes, anodizing, electronic assembly, masking, plating, photo splicing, sublimation printing, shipping, packaging, when painting cerakote or the back of automotive wheels, and many more uses at home, business or laboratory.
Shelf Life
Product shelf life is 2 years from the date of manufacture when stored at room temperature conditions (72°F [22°C] and 50% RH) in the product's original packaging.
Our Services
Customers would be provided with the below services if they are interested in our products.
A. Customized orders like different cutting sizes and die-cutting designs are all available.
B. Professional recommendations on tape choice for customers.
C. Free samples are available.
D. Competitive prices.
E. In-time delivery.
F. Quality assurance.
