Clear Mylar Adhesive Polyester Tape
* Solvent resistance
* Abrasion resistance
* Different colors for your option
Product Details
Product Description
Clear mylar adhesive polyester tape using polyester film as backing, coated with acrylic adhesive.
The clear mylar adhesive polyester tape has excellent resistance to chemicals, anti-agent, and moisture-proof capacity. Green, red, yellow, blue, transparent, and a variety of colors, and can withstand cutting and wear, with the resistance, the characteristics of insulation.
Features
* High conformity
* Chemical resistance
* Solvent resistance
* Abrasion resistance
* Different colors for your option
Application
Mylar Adhesive Tape is widely used in covering motor stator coil, wrapping of transformer coil, electrical components of the bandaged, and high-voltage isolation between the motherboard circuit and the enclosure of the switching power supply.
Construction
Acrylic Adhesive PET Film |  |
Physical Properties
Item | ||
Carrier | Polyester Film | |
Adhesive | Acrylic | |
Filling | Halogen-Free Pigment | |
Carrier Thickness | 0.025mm | 0.05mm |
Total Thickness | 0.055mm | 0.08mm |
Peel Strength Power | ≥44 N/10mm | ≥88 N/10mm |
180°Peeling Strength | ≥300 N/M | |
Elongation | ≥80% | ≥50% |
Dielectric Breakdown | ≥5.0KV | ≥6.5KV |
Heat Resistance | 150℃ | |
Cold Resistance | ≤-10℃ | |
Solvent Resistance | Ok | |
Flame Retardant | UL 510 |
These values are measured values and not guaranteed values.
Available Sizes
Width: Maximum width 1270mm. (Can be Customized)
Length: 33m/50m/66m (Can be customized).
Custom Sizes: If you need customized sizes or die-cut parts please feel free to contact the NKS sales representative
Our Services
Customers would be provided with the below services if they are interested in our products.
A. Customized orders like different cutting sizes and die-cutting designs are all available.
B. Professional recommendations on tape choice for customers.
C. Free samples are available.
D. Competitive prices.
E. In-time delivery.
F. Quality assurance.
China Heat Resistant Tape Industrial is one of the excellent manufacturers and suppliers of polyester tape, and clear mylar adhesive tape in China, which is equipped with a professional factory and advanced equipment. We aim to provide you with high-quality products with well heat resistance and strong durability which is easy to process. Welcome to buy tapes with us at a competitive price.
